8/16 Channel up to 6 kV Family with USB, Ethernet & Touchscreen

Up to 6 kV - R803x

Photo of 8/16 Channel up to 6 kV Family with USB, Ethernet & Touchscreen

The R803x is a new CAEN Power Supply Family providing 8 or 16 Independent High Voltage channels in a 2U, 19” Rack-mount unit.The channels share a Common Ground and four output ranges are available: 100 V/10 mA, 500 V/10 mA, 4 kV/3 mA (6W max), 6 kV/ 1 mA.The module is available with either positive or negative output polarity. Mixed version with 4/8 positive and 4/8 negative channels are also available.R803x units can be controlled either locally, thanks to a 2.8” touchscreen color LCD display with a complete user interface, or remotely, via USB or Ethernet, taking advantage of GECO2020 Control Software.100 V channels are delivered through BNC connectors, other versions feature SHV’s. The three high current models feature high Imon resolution of 50 nA, while the 6 kV/ 1mA has a resolution of 5 nA. Each unit is provided with Imon Zoom which increases Imon resolution by a factor 10.The HV output Ramp-up and Ramp-down rates may be selected independently for each channel.

  • 8 or 16 independently controllable HV channels in a 2U, 19″ rackmount unit

  • Versions from 100 V to 6 kV, up to 10 mA, with very low ripple

  • Local touchscreen control and remote control via Ethernet/USB

  • Multiple polarity options with protections and interlock logic

  • 100 V version with SiPM temperature compensation and fast recovery output

8/16 Channel up to 6 kV Family with USB, Ethernet & Touchscreen Models

Grid Compare
R8033

R8033

8-16 Channel 4 kV/ 3 mA (6W) 19'' Power Supply Module (USB/Ethernet/Touchscreen)
R8031

R8031

8-16 Channel 100 V / 10 mA 19'' Power Supply Module (USB/Ethernet/Touchscreen)
R8034

R8034

8-16 Channel 6 kV/1 mA Rack 19' HV Power Supply (USB/Ethernet/Touchscreen)
R8032

R8032

8-16 Channel 500 V/10 mA 19'' Power Supply Module (USB/Ethernet/Touchscreen)
R8034H

R8034H

8-16 Channel 6 kV/20 µA Rack 19' HV Power Supply (USB/Ethernet/Touchscreen)
Name
field_1
field_2
field_3
field_4
field_5
field_6
field_7
field_10
field_8
field_9
R8033

R8033

8/16

4000 V

3 mA

10 mV

Iset: 10 nA
Imon: 10 / 1 nA

500 V/s

<2 mVpp

SHV

6 W

Remote control via USB or Ethernet
R8031

R8031

8/16

100 V

10 mA

0.5 mV

Iset: 50 nA
Imon: 50 / 5 nA

50 V/s

<1 mVpp

BNC

1 W

Remote control via USB or Ethernet
R8034

R8034

8/16

6000 V

1 mA

20 mV

Iset: 5 nA
Imon: 5 / 0.5 nA

500 V/s

<2 mVpp

SHV

6 W

Remote control via USB or Ethernet
R8032

R8032

8/16

500 V

10 mA

2 mV

Iset: 50 nA
Imon: 50 / 5 nA

100 V/s

<2 mVpp

SHV

5 W

Remote control via USB or Ethernet
R8034H

R8034H

8/16

6000 V

20 µA

20 mV

Iset: 100 pA
Imon: 100 / 10 pA

500 V/s

<2 mVpp

SHV

120 mW

Remote control via USB or Ethernet

Software

Software Tools available (free download) to control the Up to 6 kV Family R803x:

  • CAEN LabVIEW: It is a set of VIs developed to configure and monitor all the parameters of remotely controlled CAEN Power Supply Modules.

  • CAEN HV Wrapper Library: it is a set of ANSI C functions bundled in a library, providing the software developer an unified software interface for the control of all the CAEN Power Supply products.

  • GECO2020: CAEN General Control SW for High Voltage Boards and Systems. it can manage and control CAEN HV power supplies in any form factor as if they were an unique device.
