64 channels
Output: 4 × 2.54 mm 34-pin male header
Compatible with standard 34-pin flat ribbon cables (e.g. A952)
RoHS compliant
The A3429 is a 64-channel adapter board for the A1429 64-channel Charge Sensitive Preamplifier.
It converts the A1429 high-density Samtec connector into four standard 2.54 mm pitch 34-pin male header connectors. The A1429 outputs can then be routed to downstream electronics using standard 34-pin flat cables, such as the A952.
|
|
Name
|
Description
|
Related Modules
|
Features
|
|
|
A3429 |
64 channel Adapter to 2.54mm Male Header Connector |
A1429 |
four 2.54mm 34 pin male header to Samtec ERF8-040-01-L-D-RA-L-TR male connector |
|
|
A371 |
Double 2.54mm 34 pin to 68-pin ERNI adapter |
V1741 Peak Sensing ADC, 740, 740D Digitizer Series |
2.54mm standard pitch, to 1.27mm ERNI connector (34 pin / 32 channels) |
|
|
A319A |
Clock & Sync cable assembly |
CAEN Digitizer Series 2.0 |
CLK-OUT / CLK-IN daisy chain front panel / 20 cm |
|
|
A319B |
Clock cable assembly Digitizer 1.0/2.0 |
CAEN Digitizer Series 1.0, CAEN Digitizer Series 2.0 |
CLK-OUT / CLK-IN daisy chain front panel between non homogenous digitizer series, / 20 cm |
|
|
A966 |
1.27mm 68 pin to four 2.54mm 16 pin cable adapter |
V862, CAEN TDC boards, V1495, V2495, DT5495 |
Adapt one (Robinson Nugent 68-pin type) flat connector into four 16-pin Header connectors / 25 cm, For ECL inputs of CAEN TDC boards or ECL ports of V1495, V2495, DT5495 |
|
|
A659 |
BNC to MCX cable adapter |
CAEN Digitizer Series 1.0 |
BNC male to MCX male / 1 m |
|
|
A643 |
SMA to BNC cable adapter |
A1423B, A1426, A1425 |
1,0 m |
|
|
N1568ADAT |
USB RS485 adapter Board |
N1568A |
converts from USB to RS-485 |
|
|
A954 |
2.54mm 34 pin to two 16 pin cable adapter |
V812, V814, V895, VME Digitizers Series 1.0, V1782 MCA, V1741 Peak Sensing ADC |
Splits the 32 used pins of a single header-type connector into 2 16pin header-type connectors |
|
|
A385 |
16 LEMO 00 or MCX to 2.54 mm 34-pin adapter |
V785, N674, V1741, A371, N568E |
16 LEMO 00 female or MCX male to 2.54 mm 34-pin female / 1 m, 50 cm |
|
|
A952 |
2.54mm 34 pin to 34 pin cable adapter |
A1442, A1429, N1068, N6741, VME Digitizers Series 1.0 / 2.0, V1782 MCA, V1741 Peak Sensing ADC, V972 |
2.54mm 34 pin female to 2.54mm 34 pin female / 50 cm |
|
|
A642 |
SMA to MCX cable adapter |
A1423B, A1426, A1425 |
1,0 m |
|
|
A372F |
2.54mm header to the 2mm header adapter |
2740/2745 Digitizer Family |
Adapts to 64 channels 2.54 mm header, Compliant to both single-ended and differential 2740/2745 models |
|
|
A392 |
16 LEMO 00 or MCX to 2.54 mm 34-pin adapter |
V792 |
16 LEMO 00 female or MCX male to 2.54 mm 34-pin female / 1 m, 50 cm |
|
|
A372M |
MCX Coax to 2mm header adapter |
2740/2745 Digitizer Family (single-ended input models) |
Adapts to 64 channels MCX, Compliant to single-ended 274xB models only |
|
|
A318 |
FISCHER S101A004 to AMPMODU IV adapter |
CAEN Digitizer Series 1.0, 741 Peak Sensing ADC |
FISCHER S101A004 male to 3-pin AMPMODU IV female for clock signal / 10 cm |
|
|
A967 |
68-pin P50 to two 2.54 mm 34-pin cable adapter |
V862, V767A, V767, V1190A/B, VX1190A/B, V1495, V2495, DT5495 |
Adapts one 3M P50E-068S (Robinson Nugent 68-pin type) flat connector into two 17+17-pin male flat-cable connectors with locks (3M 4634-7301) / 25 cm |
|
|
A992 |
16-ch Impedance adapter |
V792 |
16 independent input channels on a 34 pin male header connector, Matches the QDC’s input impedance from 50 Ohm to 110 Ohm |
|
|
A654 |
LEMO to MCX cable adapter |
CAEN Digitizer Series 1.0 |
LEMO 00 male to MCX male / 1 m |
|
Type |
Connector adapter board |
|
Channels |
24 |
|
Output Connectors |
4 × 34-pin (17×2) male header, 2.54 mm pitch |
|
Complicance |
RoHS |
