CAENComm Library

Interface library for CAEN Data Acquistion Modules

Home Firmware & SoftwareSoftware LibrarySoftware Libraries CAENComm Library

Interface library for all CAEN VME Modules, and Front End modules with USB, Ethernet, Optical Interface
Easily porting to any type of platform and VME hardware
National Instruments LabVIEW and C/C++ supported
Demo with source files included in the pack
Python binding available at pypi.org/project/caen-libs (Open Source project and examples available at github.com/caenspa/py-caen-libs)

The purpose of the CAENComm Library is to implement a common interface to the higher software layers, masking the details of the physical channel and its protocol, thus making the libraries and applications that rely on the CAENComm independent from the physical layer.
CAENComm is based on CAENVMElib, a library developed specifically for CAEN VME bridge (V3718, V4718) which implements the basic functions for accessing the VME bus (besides other specific functions for these bridge). For this reason, it is necessary that the CAENVMELib is already installed on your PC before installing the CAENComm; however, the CAENVMELib is completely transparent to the user.

Supported Operating Systems:	Windows (32-64 bit), Linux (32-64 bit)
Language:	C, LabVIEW (Windows only)
Supported Products:	VME, NIM and Desktop digitizer 720, 724, 725, 730, 740, 742, 743, 751, 761 family, Digital MCA 780, 781, 782 family and DT5790, DT55xx and V65xx power supply boards, V1x90x TDCs, V1495 and V2495 general purpose VME board, DT5495 Desktop Programmable Logic Unit and SY2791 TCP readout system
Supported Comm. Interface:	USB, Optical Link, Ethernet, VME
Additional Software Required:	CAENVMELib, NI LabVIEW Development System^* *_{only for LabVIEW package}**

Add to Wishlist

Request a Quote

Image	Name	field_1	field_2	field_3	field_4	field_5	field_6
	CAENDPP Library	High level library for CAEN Digitizers 1.0 running DPP firmware	USB 2.0, Optical Link, VME	Window, Linux	VME, NIM and Desktop digitizers running DPP-PHA firmware, Digital MCAs	C	None (CAENDPP library is standalone; only the drivers for the communication link need to be installed apart by the user)
	CAENComm Library	Interface library for CAEN Data Acquistion Modules	USB 2.0, Optical Link, Ethernet 10/100T, VME	Window, Linux	VME, NIM and Desktop digitizer 720, 724, 725, 730, 740, 742, 743, 751, 761 family, Digital MCA 780, 781 family and DT5790, DT55xx and V65xx power supply boards, A4818 USB 3.0 to CONET Adapter, V1x90x TDCs, V1495 and V2495 general purpose VME board, DT5495 Desktop Programmable Logic Unit and SY2791 TCP readout system	C, LabVIEW (Windows only)	CAENVMELib, NI LabVIEW Development System
	CAEN FERSlib Library	High level library for FERS boards	USB 2.0/3.0, Optical Link, Ethernet	Window, Linux	A/DT5202, A5203(B)/DT5203, A/DT5204, DT5215, DT5216	C	-
	New CAEN FELib Library	High level library for CAEN Digitizers	USB 2.0, USB 3.0, 1 GbE, 10 GbE, Optical Link, VME	Window, Linux	Digitizers 2.0 (2740 family and 2745 family, 2730 family), Digitizers 1.0	C, Python	CAEN Dig2, CAEN Dig1
	CAENDigitizer Library	High level library for CAEN Digitizers 1.0	USB 2.0, USB3.0, Optical Link, VME	Window, Linux	VME, NIM and Desktop digitizers 1.0, Digital MCAs	C	CAENComm, CAENVMELib, NI, LabVIEW Development System
	CAENVMELib Library	Interface library for CAEN VME Bridges	USB, Optical Link, Ethernet, VME, PCIe Gen3 x8, PCIe	Window, Linux	A4818, A5818, V/VX3718, V/VX4718, A3818, CAEN Bridges	C, LabVIEW	NI LabVIEW Development System
	CAEN PLU Library	C Library for Programmable Logic Boards	USB, Optical Link, Ethernet, VME	Window, Linux	DT5495, V2495	C	CAENComm library
